FZA Series

● The unit consists of two push buttons and one indicator light

● The push buttons are standard green type with 1NO + 1NC configuration

● The indicator light is red and rated at 220V

● Product marking shall be:

• FAZA-

• A2-2 II a2

• D1-1RF

● Executive standards: Chinese GB standards / International IEC standards / European EN standards

● Rated voltage: 220V/380V, 230V/400V; Max. 440V AC 50/60Hz; Max. 250V DC

● Ambient temperature: -40°C ~ +55°C

● Rated current: 3A (16A optional)

● Degree of protection: IP65 / IP66 (optional)

● Corrosion-proof: WF2

● Cable entry thread: PG16 (M20×1.5 optional)

● Cable outer diameter: suitable for Φ10mm ~ Φ14mm

● Enclosure material: Engineering plastics
