Explosion protection
Global (IECEx)
IECEx PCET 24.0027X
Gas and dust
Ex db IIC T6…T4 Gb
Ex db [ia Ga] IIC T6…T4 Gb
Ex db [ib Gb] IIC T6…T4 Gb
Ex tb IIIC T80°C…T130°C Db
Ex tb [ia Da] IIIC T80°C…T130°C Db
Ex tb [ib Db] IIIC T80°C…T130°C Db
Europe (ATEX)
TÜV CY 25 ATEX 0207340X
Gas and dust
II 2 G Ex db IIC T6…T4 Gb
II 2 G Ex db [ia Ga] IIC T6…T4 Gb
II 2 G Ex db [ib Gb] IIC T6…T4 Gb
II 2 D Ex tb IIIC T80°C…T130°C Db
II 2 D Ex tb [ia Da] IIIC T80°C…T130°C Db
II 2 D Ex tb [ib Db] IIIC T80°C…T130°C Db
See Selection table, P6/47~48
Certificates
IECEx; ATEX; CU-TR
Conformity to standards
EN IEC 60079-0, EN 60079-1, EN 60079-11, EN 60079-31
IEC 60079-0, IEC 60079-1, IEC 60079-11, IEC 60079-31
Enclosure material
304 stainless steel, 316L stainless steel and Q235
Exposed fastener
Stainless steel
Built-in components
Ammeters, voltmeters, power meters, tachometers, temperature control meters and other meters, control switches, disconnecting switches, moulded case circuit breakers (MCCB), miniature circuit breakers (MCB), AC contactors, thermal relays, intermediate relays, time relays, control transformers, DC power supplies, current transformers, surge protectors, PLCs, fuses, soft starters, frequency converters, terminals, bus bars, resistors, light-operated switches, time controllers, optical fiber control boxes, magnet valves, analytical instruments, heaters, self-regulation trace heating cables, display screens, magnetic ballasts of HID light sources, electronic ballasts of fluorescent lamps, drivers of LED light sources, emergency devices of HID light sources, emergency devices of fluorescent lamps, emergency devices of LED light sources, safety barriers, integrated protectors of motors, lighting building controllers, lighting energy saving controllers, fire monitoring controllers, temperature controllers, humidity controllers, current monitors, voltage monitors, motor protection switches, dual power transfer switches, counters, timers, solid state relays, diode modules, industrial personal computers, UPS, batteries
Rated voltage
Max. 1000V AC 50/60Hz
Max. 1500V DC
Rated current
Max. 1000A
Degree of protection
IP66
Ambient temperature
-60°C (-40°C) ~ +60°C (+40°C)
Cable entries
Standard M□×1.5 plug (the size of entry hole should be processed in accordance with actual requirements), NPT plug on request
Cable gland (optional)
DQM-II (Ex d) or DQM-III (Ex d) is recommended. Please see P6/24~39
Entry direction
Bottom
Mounting
Surface type (standard)
Pedestal type (optional)
