HRY92-LED Series

Explosion-proof Light Fittings for Fluorescent Lamp

Overview

  • Explosion protection compliant with CENELEC, IEC, and NEC standards
  • ATEX certification included
  • Suitable for hazardous areas:
    • Zone 1 and Zone 2
    • Zone 21 and Zone 22
    • Class I, Zone 1 and Zone 2
    • Class I, Division 1, Groups B, C, D
  • Available in two enclosure types:
    • Type I
    • Type II
  • Available lamp configurations:
    • Type I: 20W, 40W
    • Type II: 40W and 60W (including emergency versions)
  • Optimized luminous flux for improved lighting performance
  • Glass tube designed to withstand 4J impact
  • Enclosure made from copper-free aluminium alloy, powder-coated (RAL1021), corrosion-resistant
  • Built-in LED driver with wide voltage input and CC-CV (constant current–constant voltage) output, power factor ≥ 0.95
  • Cable entry thread updated to latest specification
  • Emergency function available with:
    • 40W ×15%
    • 60W ×15%
  • Emergency function available on request

Specifications

Explosion Protection

IECEx (Global)

  • Ex db IIB T6 Gb
  • Ex db IIB+H₂ T6 Gb
  • Ex tb IIIC T80°C Db

ATEX (Europe)

  • II 2G Ex db IIB T6 Gb
  • II 2G Ex db IIB+H₂ T6 Gb
  • II 2D Ex tb IIIC T80°C Db
Certifications & Standards
  • IECEx, ATEX
  • EN 60079-0 / -1 / -31
  • IEC 60079-0 / -1 / -31
Construction & Materials
  • Enclosure: Copper-free aluminium alloy, powder-coated (RAL1021), corrosion-resistant
  • Glass Tube: Toughened glass, 4J impact resistant
  • LED Driver:
    • Wide voltage input
    • CC-CV (constant current–constant voltage) output
    • Protection against overcurrent, open circuit, short circuit, surge, and EMI
  • Fasteners: Stainless steel
  • Optional Accessories:
    • Wire guard (powder-coated carbon steel or stainless steel)
    • External reflector (powder-coated aluminium)
Light Source
  • Type: SMD LED (integrated)
  • Power Options:
    • 20W, 40W, 60W
  • Optimized luminous flux for improved lighting performance
  • CRI (Ra): ≥ 80
  • CCT: 5000K
    • Optional: Warm white / Cool white
Electrical
  • Power factor ≥ 0.95
  • Wide voltage input with stable performance
Emergency Function
  • Emergency controller with battery pack
  • Protection against overcharge and over-discharge
  • Emergency Power:
    • 40W ×15%
    • 60W ×15%
  • Emergency Start Time: 0.3 seconds
  • Charging Time: 24 hours
  • Emergency Duration:
    • 120 minutes (180 minutes optional)
Electrical Data
  • Voltage: 100–277V AC, 50/60Hz
  • Earthing: M5 (internal & external earth bolts)
Protection & Environment
  • Ingress Protection: IP66
  • Ambient Temperature:
    • -60°C to +55°C (depending on configuration)
Installation
  • Terminals: 3 × 1.5–4 mm² (L + N + PE)
  • Cable Entry:
    • 2 × M25×1.5 or 2 × NPT3/4″ plugs
    • Cable gland (optional): DQM-II (Ex d)
