Accessories

● Explosion protection to

• CENELEC
• IEC
• NEC

● Can be used in
Zone 1 and Zone 2
Zone 21 and Zone 22
Class I, Zone 1 and Zone 2
Class I, Division 1, Groups A, B, C, D
Class I, Division 2, Groups A, B, C, D

Explosion protection

Global (IECEx)

IECEx CQM 25.0022X

Gas and dust

Ex db IIC Gb
Ex eb IIC Gb
Ex tb IIIC Db

Europe (ATEX)

ACE25ATEX020X

Gas and dust

II 2 G Ex db IIC Gb
II 2 G Ex eb IIC Gb
II 2 D Ex tb IIIC Db

Certificates

IECEx; ATEX; CU-TR

Degree of protection

IP66

Service temperature

-60°C ~ +100°C

Material

Copper-free Aluminium Alloy, galvanized carbon steel, nickel plated brass or stainless steel

Function

Metric thread is standard type; G thread or NPT thread is optional
To be used at spare entries of explosion-proof equipment; corrosion-proof and waterproof; supplied with seal gasket (not applicable for NPT thread)

Note

1. Please specify material when ordering. The above weight is based upon nickel plated brass
2. Metric threads are 1.5mm pitch as standard, others thread pitch can be customized, please specify when ordering
