BAM52-☐Z Series

• Explosion protection to
– CENELEC
– IEC
– NEC

• Can be used in
– Zone 2
– Zone 21 and Zone 22

• Please refer to mounting schematic diagram to select right lamp and mounting types on request of job site

• Please refer to this catalogue for detailed technical data and ordering information of each light fitting

• The street lamp is supplied without pole; please specify when ordering

• Luminaries feature adjustable brightness for efficient energy-saving lighting

• When used with an intelligent lighting system, they enable centralized intelligent management and control of lighting equipment

Explosion protection

Global (IECEx)
Gas and dust
IECEx (applied for)
Ex nR IIC T6…T5 Gc
Ex tb IIIC T80°C…T95°C Db

Europe (ATEX)
Gas and dust
ATEX (applied for)
II 3 G Ex nR IIC T6…T5 Gc
II 2 D Ex tb IIIC T80°C…T95°C Db

Certificates

IECEx; ATEX

Conformity to standards

EN 60079-0, EN 60079-15, EN 60079-31
IEC 60079-0, IEC 60079-15, IEC 60079-31

Material

Enclosure
Aluminium Alloy, powder coated surface

Glass cover
Toughened glass, stands 4J impact

LED driver
Wide voltage input, CC-CV (constant current – constant voltage) output, power factor ≥0.95,
with function of distributed current, constant current, surge-proof and anti-electromagnetic interference,
and protection against overcurrent, open circuit, and short circuit

Exposed fastener

Stainless steel

Lamp

Lamp specification
LED module

Lamp power (W)
60W, 80W, 100W, 120W, 150W, 160W, 180W, 200W

Colour temperature (CCT)

Cool white: 5700K

Note: cool white is available in general. Warm white or nature white is optional, please specify when ordering.

Rated voltage

100–277V AC 50/60Hz

Degree of protection

IP66

Ambient temperature

-40°C~+55°C (+45°C)

Terminal

3×1.5–4mm² (L+N+PE)

Mounting

Street lamp type

Cable entries

1×M20×1.5 cable gland (DQM-I Ex eb, metal unarmored)
