BHD91 Series

Explosion-proof Junction Boxes

Overview

  • Explosion protection compliant with CENELEC, IEC, and NEC standards
  • Suitable for hazardous areas:
    • Zone 1 and Zone 2
    • Zone 21 and Zone 22
    • Class I, Zone 1 and Zone 2
    • Class I, Division 1, Groups A, B, C, D
  • Available in four enclosure types: A, B, C, D
  • Manufactured from copper-free aluminium alloy, with a durable powder-coated surface for excellent corrosion resistance
  • Designed for safe and reliable cable connection and distribution in hazardous environments

Specifications

Explosion Protection
  • IECEx (Global): IECEx CQM 15.0061X
    • Ex db IIC T6 Gb
    • Ex tb IIIC T80°C Db, IP66
  • ATEX (Europe): CNEX 16 ATEX 0006
    • II 2 G Ex db IIC T6 Gb
    • II 2 D Ex tb IIIC T80°C Db
Standards & Certifications
  • IECEx, ATEX, CU-TR, UL
  • EN 60079-0 / -1 / -31
  • IEC 60079-0 / -1 / -31
  • UL 1203, UL 508, UL 50, UL 50E, UL 508A
  • CSA C22.2 No.30, C22.2 No.25, C22.2 No.14
  • CSA C22.2 No.94.1, CSA C22.2 No.94.2
Construction & Materials
  • Enclosure: Copper-free aluminium alloy, powder-coated
  • Colour: Window grey (RAL7040)
  • Fasteners: Stainless steel
Electrical Data
  • Rated Voltage: Max. 500V AC
Rated Current & Terminal Data
Cross Section Rated Current Terminal Number
2.5 mm² 24A 12
4 mm² 32A 10
6 mm² 41A 8
Protection & Environment
  • Ingress Protection: IP66
  • Ambient Temperature: -60°C to +60°C
  • Earthing: M5 (internal & external earth bolts)
Installation
  • Cable Entry: Standard M20 × 1.5 plug
  • Optional: NPT plug available on request
  • Cable Gland (optional): DQM-II (Ex d) or DQM-III (Ex d)
